130 kW Generator
130kW generator powered by a Volvo diesel engine and Stamford alternator for commercial application
Generator Description
General Information:
SKU: 042320
Volvo Penta TAD551GE Engine
7.15 liters, 6 inline cylinders
Certified for US/EPA Tier 3 y EU STAGE 3A
Power: Standy by 114 kWm / Prime 100 kWm
Alternator: 24V/55A
Starter: 24V/5kW
Sensor for oil pressure and temperature, coolant temperature, fuel pressure, and speed sensor
The Engine Management System 2 (EMS 2), an electronically controlled processing unit that optimizes engine performance.
Control panel
Control Module: DEEP SEA DSE7320.
Continuous voltage range: 8v a 35V.
LCD text display in up to 7 languages
Configurable Alarms
Automatic Shutdown: Under-voltage, overload, low frequency, low coolant level, overcurrent, low oil pressure
Breaker box
Brand: ABB
Model: TMAX XT5N 600
Number of poles: 3
Molded case
Maximum short-circuit breaking capacity (Icu):240Vac 65KA.
Rated current (In): Main circuit 600A
Certification: UL
Mechanical terminals
Tank
Diesel sub-base tank
600 or 900 US gallons
Double wall
Material: Mild steel
Six lifting points
Voltage
1PH - 120/240v
3PH - 120/208v
3PHM - 120/240v
3PHH - 277/480v
Cabin
Sound attenuation material: Up to 2" of closed-cell foam acoustic insulation
Vertical discharge of hot air
Access doors: 05
Hinges and door locks: stainless steel material
Warranty
This generator has a warranty of:
02 YEARS or 2000 hours
Request your quote
Complete the request and a authorized representative will contact you as soon as possible
